THz Optoelectric Unit

Characterization of Terahertz Optoelectronic Components

Impulse and time-domain characterization of photodetectors with ultra-short response times (1 ps – >1 ns)
→ Application to the generation and detection of pulsed THz signals.

Equipment:

  • Femtosecond lasers @ 780 nm and 1550 nm
  • High-speed oscilloscope (1.5 GHz bandwidth)
  • Optoelectronic equivalent-time characterization bench (1 ps resolution)
Opto1
Small volumes materials characterization

On-chip characterization of small material volumes (< 1 mm³) in the 50–500 GHz band.

Equipment:

  • Femtosecond laser
  • Integrated THz component (GaAs-based device or TeraLineX component, Protemics GmbH) and dedicated measurement bench
Opto2
Characterization of materials for THz generation/detection

It is possible to obtain information on the nonlinear properties of a material by analyzing the THz signal it emits when pumped by an optical fs pulse. For this type of characterization, the platform is equipped with:

  • An MKS Synergy laser (800 nm, 12 fs, 75 MHz, 1 W)
  • A Coherent LIBRA amplified laser chain (800 nm, 50 fs, 1 kHz, 5 W)
  • A Light Conversion TOPAS Prime OPA (output wavelength range from 2.6 µm to 285 nm, i.e., from 0.48 eV to 4.35 eV)
  • A Daheng New Epoch Technology ABCD DH-ZAP-APD detector
  • Various nonlinear crystals (ZnTe, GaP, GaSe, …)
  • Photoconductive antennas
Opto3

Reference:
Dongwei Zhai, Emilie Hérault, Frederic Garet, Jean-Louis Coutaz, Ci-Ling Pan. THz generation in GaSe crystals pumped with laser photon energy below and around the bandgap. Applied Physics Letters, 2023, 122 (1), pp.011103.
